Parameter:

Work table(cm)	Voltage (V)	Power (KW)	Time.range(S)	Temperature	Pressure(kg/cm2)	Packing size(cm)
38x38	220	2.2	0 - 999	0-399	0 – 8	84x49x77
40x50		3.0				84x65x77
40x60	220/380	3.7				81x67x77
50x60		3.8				89x79x84
50x70		4.0				84x99x84
60x80		6.0				84x109x84



Machine Features:

1.Digital Control , makes working procedure complete situation uses signal indication,has the high accuracy.

2.The radiation pipe and the hot plate in whole,safe,durable,and distribute heat averagely.

3.Free to adjust the pressure,widely used in the factory assembly line operation.

4.Adopt IC board, touch buttons, electromagnetic switch and ON/OFF timer, providing elegant appearance and high reliability.

5.Stable running,deforming free and low noise

6.Automatic control,even and stable pressure (pressure up to 8KG/CM2)

4.Two optional running modes for work bench manual and automatic

7.Dual-side pull type work bench saves labor and provides high printing speed

8.Using special security devices,the machine is anti-crushing, safe and rationalized

9.Surrounding design is adopted for special tube of heating panel,ensuring uniform heating

10.Specially treated working table is suitable for printing products for sublimating,heat transfer printing and gilding
